Manual Drum Tilter and Lifter
MANUAL DRUM TILTER AND LIFTER
MKP 159
Cap: 300 kgs
Raised ht: 1400 to 4000 mm
Raised ht: 1400 to 4000 mm
We are known as one of the leading manufacturers and suppliers of drum handling equipments in the country. Our company designs and develops these equipments for standard drums. All the drum clamping, lifting and tilting stackers are constructed with strong raw materials to ensure strength and excellent results during operation. Our lifting and tilting stackers have vast demand in the competitive market because all the items are finished with special care keeping in mind the market trends.
Features
- Picks up drum vertically off the floor or pallet, transports to destination, lifts to the required height and deposits, where required.
- Can handle open drums, hazardous/high temperature liquids, etc without spillage.
- Can stack drum vertically one above the other without the use of pallets.
- Can place drums on mezzanines, catwalks, platform, etc.
- One man, safe operation.
- Available with electro hydraulic, flameproof electro hydraulic, battery powered lift and manual hydraulic lift models.
- Available GMP - stainless steel models.
- 250 kg, 350 kg and 500 kg capacities with lift up to 4 meters.
- DOST - the most user-friendly drum stacker.
Specifications
| Product Code | MKP-159 | MKP-159 | MKP-159 | MKP-159 | |
| Rated Capacity | kg | 300 | 300 | 300 | 300 |
| Max. Lifting Height | mm | 2000 | 2500 | 3000 | 4000 |
| Overall Length | mm | 1300 | 1300 | 1300 | 1300 |
| Overall Width | mm | 1000 | 1000 | 1000 | 1000 |
| Overall Height | mm | 2000 | 2000 | 2000 | 2400 |
| Self Weight | kg | 150 | 165 | 190 | 200 |
